The scientific research conducted as part of the doctoral dissertation titled:

Prosody of Speech in High-Functioning Individuals with Autism Spectrum Disorders

Supervisor:

dr hab. Marzena Stępień, prof. UW

Reviewers:

  • dr hab. Urszula Mirecka, prof. UMCS
  • dr hab. Piotr Sobotka, prof. IS PAN

From scientific research to UX research

I developed a universal tool to diagnose and analyze disturbances in pitch, intonation, rhythm, and emotions in all speech distortions where there are issues with perceiving and producing these sound characteristics.

The research confirmed the clarity and usability of the electronic version of the tool and provides a solid foundation for further UX research on developing a specialized application for diagnosing prosodic speech disorders.

The next stage of work will involve developing an interface that allows users to self-assess their skills in perceiving pitch, intonation, rhythm, and emotions in speech.

Assessing the ability to produce prosodic speech requires involvement of specialists in speech therapy. The development of AI may soon enable the use of technology in this process.

The scientific research I conducted was in many ways analogous to UX research. My research and graphic design skills, along with my knowledge of UX/UI, will allow me to continue working on an application to study prosodic speech perception.

Defining the research problem

What did I research?

Difficulties related to the perception and expression of linguistic and emotional prosody in high-functioning individuals with autism.

So what exactly?

Prosody

Prosody is the sound properties of speech. There are two types of prosody:

Linguistic prosody
  • Word and sentence stress
  • Intonation
  • Rhythm
Emotional prosody
  • Joy
  • Anger
  • Sadness

In communication, we use two cognitive processes:

Speech perception

Receiving, recognizing, and interpreting speech sounds.

Speech expression

Expressing thoughts, feelings, information, and intentions using words.

Autism

Autism spectrum disorder is a different way of functioning, sensing, and processing sensory stimuli, language information, and social behaviors.

Why did I conduct research?

Advancement of science

Research on prosody disorders in people with autism contributes to the development of linguistics, while also filling a research gap in this field.

Lack of such research in Poland

Local researchers only note the presence of these irregularities, while foreign specialists examine their type and severity.

Differences between languages

Due to cultural and linguistic differences in emotional and linguistic prosody, the results of studies conducted in other languages cannot be easily applied to Polish.

What did I want to find out?

  1. Which components of the prosodic system do the subjects have difficulty with?
  2. Are their prosody speech disorders continuous or sporadic?
  3. Which is more problematic for them – the perception or expression of prosodic elements?
  4. Which type of prosody deviates more from the norm – linguistic or emotional?

Developing the research tool

What research tool did I use?

I conducted the research using my own custom tool:

A questionnaire for assessing prosodic listening and prosody speech expression.

What did I do before developing the questionnaire?

I analyzed other foreign and Polish research tools of this type.

Foreign tools for assessing speech prosody

Comparison of prosody assessment tools by study type and examined features
L Linguistic E Emotional Yes No
Prosody under study Perception study Expression study Examined features
L Linguistic E Emotional Yes No

Polish tools for assessing speech prosody

Comparison of emotion perception and expression tests by study type and examined features
L Linguistic E Emotional Yes No
Prosody under study Perception study Expression study Examined features
L Linguistic E Emotional Yes No

Conclusions

Foreign research tools

They are used to study speech perception and expression.

For perception, they most often assess intonation and emotional prosody.

For expression, they check word and sentence stress, intonation, as well as voice pitch and intensity.

Polish research tools

They focus solely on studying perception. They mainly assess intonation and emotional prosody.

How did I construct the research tool?

Versions of the questionnaire

Paper version
Electronic version

Studies in the questionnaire

Study of the Perception of Linguistic and Emotional Prosody
Study of the Expression of Linguistic and Emotional Prosody

Diagnosed prosodic features

  • word stress
  • sentence stress
  • intonational contours
  • rhythmic structures
  • emotional prosody

Conducting the research

What did I do before conducting the research?

Pilot studies

I assessed the clarity of the questionnaire instructions and task content, as well as the effectiveness of the procedures under specific conditions. The results showed that the prepared materials are understandable for the participants and the data collection methods are effective in the planned research conditions.

What did I do before conducting the research?

Autism is diagnosed four times more often in men than in women, so I invited only men for the study.

The study involved individuals with autism (experimental group) and individuals without autism (control group).

I recruited men with autism through foundations working for people with autism.

I recruited men without autism from volunteers.

Group characteristics / Participant selection criteria

Experimental group
  • 10 men aged 21-35 years
  • Individuals diagnosed with high-functioning autism
  • Individuals without diagnosed additional disorders
  • Individuals who could communicate verbally and read with comprehension
Control group
  • 10 men aged 25-34 years
  • Typically developing individuals
  • Individuals without hearing impairment or auditory processing disorders
  • Individuals without intellectual disabilities

Under what circumstances and conditions did I conduct the research?

Course of the study

I assessed perception and expression of speech prosody separately.

Participant comfort

Participants sat at a table. If needed, they could listen to each recording again and take breaks.

Privacy and confidentiality

I informed participants about what and how would be examined and the rules for collecting, processing, and storing data, including personal data.

Location of the study

I conducted the research in a therapy office or another quiet location.

Participant tasks

People decided which of the narrator's utterances sounded correct and responded according to instructions.

Recording the study

I recorded the expression of speech prosody study using a voice recorder.

Judge recording reviews

How did I manage the recordings?

Compilation of recordings

Recordings before segmentation

20 expression studies = 20 recordings

Segmentation of recordings

Recordings after segmentation

Total of 2000 files (1000 in each group)

Storage of recordings

Google Drive

I placed all files on a password-protected network drive.

Sharing the recordings

Platform jotform.com

I created interactive forms where each speech recording had its own player.

Who evaluated the recordings and how?

4 qualified judges

  • Individuals with knowledge in speech therapy.

Rules for conducting the expertise

  • Familiarize themselves with the instructions for completing the forms.
  • Read the instructions given to the participant.
  • Listen to, comment on, and evaluate all voice recordings.
  • No access to information about which recording belonged to a person with autism and which to a person without autism.
  • No possibility of consulting with each other.

How did the judges evaluate the recordings?

The judges listened to, commented on, and assessed the recordings of the participants' speech using forms.

Listening

Media player
  • It is connected to the audio file stored on a network drive.
Analysis method – perceptual evaluation
Main drawback of the method
  • Subjectivity of the assessment
Countermeasures
  • Obtaining opinions from multiple people
  • Introducing a rating scale

Commenting (3 ways)

Selection from a list
  • Predefined statement matched to a prosodic feature
  • Mandatory
Supplementary comment (text field)
  • Justification for the decision
  • Optional
Additional comment (text field)
  • Separate notes and observations without affecting the assessment
  • Optional

Evaluation

Rating from a list
  • Three-point scales
  • Matched to the content of the comment
  • Mandatory
Supplementary comment (text field)
  • Justification for the decision
  • Optional
Type of realization Score
correct, well audible 1 point
correct, poorly audible 0.5 point
hypercorrect 0.5 point
unclear 0 point
incorrect 0 point
other 1 point
other 0.5 point
other 0 point

Analysis and results

What results did I get?

Results of perception study

Lexical stress

Total points in %

People with autism

81%

People without autism

92%

Results

Both groups had no problem perceiving stress in two-syllable words.

Differences between the groups appeared in the perception of stress in three-syllable words, reflected in the number of errors made.

Sentence stress

Total points in %

People with autism

99%

People without autism

100%

Results

People from both groups correctly identified the most strongly stressed words in sentences spoken by the speaker.

Intonation

Total points in %

People with autism

94%

People without autism

97%

Results

Men from both groups had no problem recognizing the rising intonational contour of questions, achieving full accuracy.

People with autism made 10 percentage points more errors by identifying exclamatory sentences as declarative.

Rhythm

Total points in %

People with autism

50%

People without autism

82%

Results

People with autism made mistakes 18 percentage points more often in the case of two-syllable words and 26 percentage points more often in the case of three-syllable words, and their errors concerned all combinations of stress on syllables.

Emotions

Total points in %

People with autism

99%

People without autism

99%

Results

People from both groups had no problem with auditory differentiation of emotions.

Results of expression study

Lexical stress

Experimental group vs. control group

People with autism

-26 p.p.

Correct and clearly audible use of paroxytonic stress (code AL1).

People with autism

+2 p.p.

Hypercorrect use of stress (code AL3).

The most common mistake

People with autism

7%

Use of two stresses (scansion) (code AL6).

People with autism

7%

Use of stress on the last syllable of the word (code AL5).

People without autism

2%

Use of two stresses, on the first and last syllable of the word (code AL13).

Sentence stress

Experimental group vs. control group

People with autism

+11 p.p.

Incorrect use of stress.

The most common mistake

People with autism

11%

People without autism

6%

Use of sentence stress on multiple words in the utterance, with one being stressed correctly, in accordance with the given question (code AZ8).

Intonation

Experimental group vs. control group

People with autism

+9 p.p.

Incorrect use of intonation.

The most common mistake

People with autism

6%

Use of anti-cadential intonation, inappropriate for a declarative sentence (code KI5).

People without autism

2%

Inappropriate speech expression of interrogative sentences, sounding like exclamatory questions (code KI13).

Rhythm

Experimental group vs. control group

People with autism

-1 p.p.

Incorrect rhythmic patterns disrupted by symptoms of fluency disorders (code SR6).

The most common mistake

People with autism

13%

Vowel elongation (code SR6.4).

People without autism

12%

Use of inter-word pauses of similar length (code SR6.9).

Emotions

Experimental group vs. control group

People with autism

+13 p.p.

Incorrect expression of emotions.

The most common mistake

People with autism

7%

People without autism

6%

Unclear realizations, where it was difficult to determine the emotional state in which the sentence was uttered (code PE4).

Did the judges agree with each other?

I assessed the level of agreement among the evaluators using the kappa coefficient. Before taking measurements, I encoded the content of comments from the selection list and selected the appropriate measure.

Encoding comments

I encoded comments from the selection list in three steps:

  1. 1

    I downloaded the data from the forms in CSV files format

  2. 2

    I merged the CSV files using the Power Query add-in in Excel

  3. 3

    I converted the comment contents into codes

To each comment from the selection list, I assigned an identification code consisting of the first two letters of the evaluated prosodic feature's name and a number, for example, the code AL1 refers to the first comment from the selection list in the lexical stress expression study. Ratings (points) did not require coding.

Agreement coefficient

The level of agreement among judges, both in terms of the comments they selected and the ratings they assigned, was assessed using the AC1/AC2 coefficient.

The AC1/AC2 parameter proved to be particularly useful due to its resistance to the well-known paradox in the literature related to the tendency of kappa-type coefficients to assume low values when there is a large number of identical data, which often leads to incorrect conclusions about the lack of agreement among judges.

Values of comments vs. ratings agreement coefficients

Both groups

Throughout the study, the values of comment coefficients were generally lower than the values of rating coefficients.

Conclusion

Judges more often disagreed with each other regarding the reasons for irregularities than regarding the fact of their occurrence.

People with autism

Throughout the study, the values of comment and rating coefficients were generally lower in the experimental group.

Conclusion

Judges had a greater difficulty achieving agreement regarding the correctness of prosodic structure realizations produced by individuals with autism.

Exception: Study of rhythmic structure expression

Both groups

Throughout the study, the values of comment and rating coefficients were generally diverse.

People with autism

Throughout the study, the values of rating coefficients were generally slightly higher in the study group.

Conclusion

Judges did not agree on the correctness of rhythmic patterns pronounced by both individuals with autism and typically developing individuals.

What are the responses to the research questions?

  1. Which components of the prosodic system do respondents have difficulty with?

    Linguistic prosody

    Deficits in prosodic functions:

    • misplaced lexical or sentence stress;
    • inappropriately chosen or well-chosen but lacking expressive force intonation contours;
    • stilted rhythm and slowed speech tempo.

    Emotional prosody

    Diminished prosodic form characterized by unclear articulation, i.e., hindering the recognition of emotional content.

    Differences between groups

    Differences pertained to the severity of abnormalities; they were quantitative rather than qualitative. Individuals with autism made more errors of the same type than neurotypical individuals.

  2. Do speech prosody disorders have a continuous or sporadic nature in their case?

    Prosodic disorders in individuals with ASD may manifest as a consistent aspect of speech or only occur in specific situations or types of utterances.

  3. What causes them more problems – perception or expression of prosodic elements?

    In individuals with autism, the production of prosodic structures is more disrupted than their perception. However, there is much evidence to suggest that difficulties in their production are not related to a lack of ability to understand them.

  4. Which type of prosody deviates more from the norm – linguistic or emotional?

    Research results showed that in individuals with autism, emotional prosody was not more disturbed than linguistic prosody. Both types of prosody were equally distorted.

Many issues related to the prosody of individuals with autism require further research and analysis..

What people are saying

I’m happy to answer some questions
